USB充電器外殼包膜機
USB charger shell coating machine
【USB充電器外殼包膜機】基本說明
(USB charger shell coating machine)Basic instructions
產品名稱:USB充電器外殼包膜機
產品別名:手機充電器貼膜機、貼保護膜機
· 產品型號:B-HTBM2013
· U S B孔:自動沖孔
· 切斷方式:自動切斷
· 包膜方式:自動旋轉
· 自動化程度:腳踏
· Product name: USB charger shell coating machine
Synonyms: mobile phone chargers film machine, stick protective film machine
· · Model: B-HTBM2013
· ·U S B hole: automatic punching
· · cut: automatic cutting
· · envelope: automatic rotation
· · degree of automation: Foot
【USB充電器外殼包膜機】性能特點 [USB charger shell coating machine] Features
基本性能:專門針對手機充電器外殼進行包膜,防止運輸、人為觸摸產生的刮傷及污漬
控制性能:采用PLC控制器控制步進電機及精密氣缸;治具沖壓成型、自動沖出USB孔、自動包膜、 裁斷膜料,動作更穩??;易于維護(節約成本,減少人工)。
顯示性能:觸摸屏可進行參數設置;包膜速度設置;顯示已包膜數量等。更直觀,更方便操作。
便操作性:通過腳踏開關的開啟和關閉,使用氣泵和電源控制氣缸的伸出返回。沖出USB孔及包膜裁斷。
Basic performance: specifically for the mobile phone charger shell were coated to prevent scratches and stains transport, human touch produced.
Cool Performance: PLC cooller and precision stepper motor cylinder; fixture sping, automatic out USB hole, automatic envelope, cutting film material, more robust action; ease of maintenance (cost sings, reduce labor).
Display Performance: touch screen set parameters; envelope speed settings; displays quantity capsule. More intuitive, more convenient operation.
Convenient operation: The foot switch is opened and closed, using the air pump and power cool cylinder extends returned. USB hole and cutting out the envelope.
【USB充電器外殼包膜機】適用范圍[USB charger shell coating machine] Scope


【USB充電器外殼包膜機】技術參數[USB charger shell coating machine) technical parameters
| 參數名稱 | 單位 | 參數值 | |
| 額定電壓 | V | 220 | |
| 觸摸屏 | 工作電壓 | V | 220 |
| 功率 | W | 50HZ | |
| 氣缸 | 氣壓 | Mpa | 0.5-0.8 |
| 理論作用力 | N | 11-17 | |
| 力距 | Nm | 1.5 | |
| 負荷 | N | 6.3 | |
| 連續工作時間 | 市電供電 |
| 長時間 |
| PLC | 點數 |
| 32點以下(微型) |
| LD指令處理器 |
| 硬PLC | |
|
|
| 可編程控制 | |
| 產量 | PCS | 2.3/S | |
| 外觀尺寸 | MM | 720×520×650 | |
| 重量 | KG | 100 | |
【USB充電器外殼包膜機】售后服務[USB charger shell coating machine] Service
感謝您選購本公司USB包膜機產品,本產品嚴格按照ISO9001國家質量體系標準進行質量控制。機械整機保修一年、易損件如沖壓切斷保修3個月,自購買之日起一年內產品出現非人為損壞故障由本公司負責免費維修。終身提供產品維護和技術支援。機器如出現問題,我司知悉后24小時內到達現場處理。
Thank you for purchasing our USB coating machine products, the product in strict accordance with ISO9001 quality system standards for quality cool. Machinery whole year warranty, wearing parts such as sping cutting edge 3 month warranty from date of purchase within one year of non-human damage product failure by the Company responsible for the free repair. Lifetime supply of product maintenance and technical support. Machines such as problems, I know the Secretary within 24 hours to reach the scene.
