供應(yīng)LFL3-CK-U-PVC5浮球液位開關(guān)

電氣特性

觸點負載

230 V AC/3 A/200 VA; 150 V DC/3 A/100 W resistive load

額定絕緣電壓

300 V

脈沖耐受電壓

4 kV

指令符合

Low voltage

Directive 2014/35/EU

EN 60947-5-1:2004 + Cor.:2005 + A1:2009

Conformity

防護等級

IEC 60529:2001

Application

描述

mercury (Hg) change-over contact

Function and system design

Equipment architecture

This device may be used with any sequential circuit, as long as the circuit can support the electrical circuit values of the switching elements.

操作條件

安裝條件

Installation instructions

range of application and minimum length between mounting and float:
- PVC version: ≥ 50 mm (2 inch), preferred for water
- PUR version: ≥ 100 mm (4 inch), preferred for fuels, heating oils, oily fluids
- CSM/CM version: ≥ 100 mm (4 inch), preferred for many acids and lyes
- TPK version: ≥ 100 mm (4 inch), preferred for many acids and lyes
mounting:
- The float switch is mounted either from sidewards through a cable gland ≥ G1A into the vessel or
- by means of a counter weight or rods (e. g. float switch combination) from the top.
The pivot of the cable should always be horizontal.

Process conditions

過程壓力(靜壓)

sleeve design: ≤ 3 bar at 20 °C (68 °F)
ball design: ≤ 2 bar at 20 °C (68 °F)

Density

sleeve design: ≥ 0.8 g/cm³
ball design: ≥ 0.6 g/cm³

周圍環(huán)境

環(huán)境溫度

PVC version: 5 ... 70 °C (41 ... 158 °F)
PUR version: 5 ... 70 °C (41 ... 158 °F)
CSM/CM version: -20 ... 70 °C (-4 ... 158 °F)
TPK version: 5 ... 70 °C (41 ... 158 °F)

儲存溫度

-25 ... 70 °C (-13 ... 158 °F)

海拔

≤ 2000 m above MSL

機械特性

防護等級

IP68

Mechanical construction

材料

float: PP (Polypropylene)
cable:
- PVC version: PVC cable, highly flexible (3 x 0.75 mm²)
- PUR version: PUR cable, highly flexible (3 x 0.50 mm²)
- CSM/CM version: CSM/CM cable (chlorinated polyethylene, (3 x 0.75 mm²))
- TPK version: TPK cable, (3 x 0.75 mm²)
