泰州通洋折疊機，全自動被單折疊機，折疊機廠家

全自動折疊機

參數                  單位             ZD3300-V

折疊長度*寬度          mm               3600*3300

工作能力（普通床單）        m/min               30

額定輸入功率              kw              0.75+0.37

耗電量                 kw/h                0.6

外形尺寸                mm              4940*2530*1930

產品說明：

簡要說明
1、采用大屏幕點陣液晶顯示及智能化控制系統，并且有良好的全中文人機對話界面。
2、在電腦監控下完成5次折疊，縱折和橫折次數可按織物幅度、厚度自由編程。
3、采用高智能化的紅外線檢測系統，取消了傳統的機械脈沖計數裝置。
4、具有雙通道折疊功能，可雙倍提高小型布草的熨平折疊能力，降低能耗。
5、運轉速度調節范圍大，能與各種相應的熨平機匹配。
6、具有自診斷功能，完善的安全保護系統，檢測點自保養功能。
7、電腦板采用繼電器輸出，無需中間繼電器，減少了故障點，維修檢測方便。
8、各控制組件均采用直流24V低壓組件，安全可靠，便于直接維修。
9、各控制閥均采用氣動控制，動作迅速可靠，對周圍環境無污染。
10、本設備多處裝有安全開關，使用安全可靠。

Instruction
1．Adopted big screen and intelligent cool system，the machine has interactive function．
2．Five times of folding can be finished under the cool of computer．The number of times and the directions of folding can be programmed freely according to the range and thickness of fabrics．
3．The traditional counter of mechanical pulsing has been replaced by infrared testing system of high intelligence．
4．With the function of double channel folding，it can se energy double．
5．The running speed can be adjusted widely to be suitable for various ironing machines．
6．It has the functions of automatic diagnosis，perfect safety system and self-maintenance for testing points．
7．The computer board adopts relay output and there is no intermediate relay．It may reduce troubles greatly，and maintenance becomes easy．
8．All cool components use 24V DC．It is not only safety，but also easy to maintain directly．
9．All cool valves are coolled by pneumatic system and all actions become quick and reliable．
10．Equipped with several safety switches in different itions．the machine is safe and reliable.
