長江機械直銷CHM-a4復印紙生產線
【a4復印紙生產線】性能特點
CHM-A4-4/5 A4 復印紙生產線螺旋線刀槽搭配無間隙齒輪,實現了上的雙回旋同步剪切的切斷新工藝,是集令紙分切、包裝、令紙包裝箱自動化一體的復印紙加工生產設備。
A4 copy paper sheeting and wrapping machine CHM-A4-2/4/5A4 copy paper sheeting and wrapping machine . This production line adopt the most advanced twin Rotary knife synchronize sheeting , ream wrapping and box wrapping fully automatic.
【a4復印紙生產線】技術參數
切紙型式(Cutting Type)
CHM-A4-4/5
紙卷寬幅(Paper Width)
1055mm-1060mm
生產運行速度(Production speed)
Max280m/min
切紙精度(Cutting accuracy)
±0.2mm
上紙卷數(Paper Rolls number)
4卷/5卷(4Rolls/5Rollls)
分裁數(Cutting numbers)
4裁/5裁(4 Cutting /5 Cutting)
產量(Output of the ream)
Max 37令/47令/每分鐘(Max 37/47Reams/min)
整機功率(Power )
32kw+18kw+19kw
機器尺寸(Dimension(L×W×H))
20114mm*13271mm*3190mm
【a4復印紙生產線】產品照片
