供應皮爾磁安全繼電器PNOZ S7繼電器PNOZ s7 24VD

上海尚帛供應皮爾磁安全繼電器PNOZ s7 24VDC 4no 1nc

訂貨號：750107

具體型號價格歡迎來電垂詢！

技術(shù)參數(shù)

批準: CE, cULus 認證, T?V, KOSHA, CCC
應用選項: 瞬時觸點擴展
供電電壓 (V): 24,0
在DC1處的電流: 6.0 A
在AC1處的電壓: 240 V
終端類型: 螺絲端子
終端型: 插件
標準: EN 60204-1, EN 62061, EN ISO 13849-1, VDE 0113-1
操作模式: 單通道, 不檢測觸點間短路
瞬時安全觸點數(shù)量: 4
寬度尺寸: 17.5 mm
高度尺寸: 98.0 mm
深度尺寸: 120.0 mm
總重: 180 g
凈重: 170 g
以攝氏度一表示的環(huán)境溫度: -10 - 55 °C

其他訂貨號

750002 PNOZ s Set screw terminals 12,5mm
750003 PNOZ s Set screw terminals 17,5mm
750004 PNOZ s Set screw terminals 22,5mm
750008 PNOZ s Set1 screw terminals 45mm
750012 PNOZ s Set2 screw terminals 45mm
750020 PNOZ s connector
750101 PNOZ s1 24VDC 2 n/o
750102 PNOZ s2 24VDC 3 n/o 1 n/c
750103 PNOZ s3 24VDC 2 n/o
750104 PNOZ s4 24VDC 3 n/o 1 n/c
750105 PNOZ s5 24VDC 2 n/o 2 n/o t
750106 PNOZ s6 24VDC 3 n/o 1 n/c
750107 PNOZ s7 24VDC 4 n/o 1 n/c
750108 PNOZ s8 24VDC 2 n/o
750109 PNOZ s9 24VDC 3 n/o t 1 n/c t
750110 PNOZ s10 24VDC 4 n/o 1 n/c
750111 PNOZ s11 24VDC 8 n/o 1 n/c
750126 PNOZ s6.1 24VDC 3 n/o 1 n/c
750134 PNOZ s4 48-240VACDC 3 n/o 1 n/c
750135 PNOZ s5 48-240VACDC 2 n/o 2 n/o t
750136 PNOZ s6 48-240VACDC 3 n/o 1 n/c
751002 PNOZ s Set spring loaded terminals 12,5m
751003 PNOZ s Set spring loaded terminals 17,5m
751004 PNOZ s Set spring loaded terminals 22,5m
751101 PNOZ s1 C 24VDC 2 n/o
751102 PNOZ s2 C 24VDC 3 n/o 1 n/c
751103 PNOZ s3 C 24VDC 2 n/o
751104 PNOZ s4 C 24VDC 3 n/o 1 n/c
751105 PNOZ s5 C 24VDC 2 n/o 2 n/o t
751106 PNOZ s6 C 24VDC 3 n/o 1 n/c
751107 PNOZ s7 C 24VDC 4 n/o 1 n/c
751108 PNOZ s8 C 24VDC 2 n/o
751109 PNOZ s9 C 24VDC 3 n/o t 1 n/c t
751110 PNOZ s10 C 24VDC 4 n/o 1 n/c
751111 PNOZ s11 C 24VDC 8 n/o 1 n/c
751126 PNOZ s6.1 C 24VDC 3 n/o 1 n/c
751134 PNOZ s4 C 48-240VACDC 3 n/o 1 n/c
751135 PNOZ s5 C 48-240VACDC 2 n/o 2 n/o t
751136 PNOZ s6 C 48-240VACDC 3 n/o 1 n/c
751156 PNOZ s6.1 C 48-240VACDC 3 n/o 1 n/c
