SD ZINC PRIMER 500 環氧富鋅底漆 500
PRODUCT DEION
產品簡介
A high-build organic zinc rich anti-corrosive coating based on epoxy resin, polyamide hardener and
zinc powder
厚涂型環氧富鋅防腐漆，由環氧樹脂、聚酰胺及組成
RECOMMENDED USE
用途
For steel structure at industrial severe corrosive environment
用于工業環境下嚴酷腐蝕環境的鋼結構表面
COMPLIED STANDARDS
符合標準
Complies with ISSSPC PAINT 20、HG/T
符合ISSSPC PAINT 20、HG/T富鋅底漆中的成分要求
FEATURES
產品特性
Remarkable corrosion resistance
的防腐性能
High build applicability
良好的厚涂施工性
Quick drying
干燥迅速
Excellent resistance to abrasions and impacts
極好的耐磨損、耐沖擊性能
Long-term protection when used with epoxy coatings
與環氧涂料配套時可提供長期的保護
PHYSICAL PROPERTIES
基本數據
Color
顏色
Volume Solids
體積固體份
VOC
揮發性有機化合物含量
Flash Point
閃點
Film thickness
涂裝膜厚
Theoretical Coverage
理論涂布率
Grey
灰色
58%
365g/L，accord with EU DircrtiveEC，subcategory j
365g/L，符合歐盟排放指令EC，j 子類別
Greater than 19℃
19℃以上
Drymicrons/coat Wetmicrons/coat
干膜微米/道濕膜微米/道
0.232kg/m2/50 microns
0.232 千克/平方米/50 微米
Practical coverage depending on surface conditions, environment, applications, etc.
實際涂布率與表面處理, 外界環境, 施工方法等多種因素有關。
APPLICATION
施工
Application Temperature
施工溫度
Mixing
混合
Mixing Ratio
混合比例
5℃-40℃
Combine Base with Hardener, mix thoroughly with power agitator
混合主劑與固化劑，使用動力工具攪拌均勻
Base/Hardener=19/1(by weight)
主劑/固化劑=19/1（重量比）
Pot Life
混合使用期
Application Methods
施工方法
Thinner
Drying time &
Overcoating interval
干燥時間&涂裝間隔
Applied Substrate
適用底材
Typical topcoat
適用上涂
5℃ 10℃ 20℃ 30℃
16hrs 12hrs 8hrs 6hrs
Airless spray, air spray, brush and roller
無氣噴涂、空氣噴涂、刷涂、滾涂
Airless spray 無氣噴涂
Nozzle tip 噴嘴尺寸0.43mm-0.53mm
Nozzle pressure 出口壓力≥10Mpa
Thinning ratio 稀釋比率0-10% by weight（重量比）
Brush/Roller 刷涂、滾涂
Thinning ratio 稀釋比率0-10% by weight（重量比）
Epomarine Thinner
環氧漆
Temperature 溫度5℃ 20℃ 30℃
Surface dry 指觸干燥30mins 20mins 10mins
Touch dry 半硬干燥7hrs 4hrs 3hrs
Min. interval 最小涂裝間隔24hrs 24hrs 4hrs
Max. interval 涂裝間隔
Bare steel
裸鋼
Universal EP-50, EPOMARINE EX-500 or according to the coating system of Cosco Kansai.
通用環氧漆EP-50，環氧漆EX-500 或參考我司涂裝配套
STORAGE
貯存
Shelf life
貯存期限
Store in dry, cool condition and away from sources of heat and ignition. Containers must be kept
tightly closed.
貯存于干燥陰涼的環境中，遠離熱源及火源。包裝桶必須保持封閉。
12 months from date of production (25℃)
自生產之日起12 個月（25℃）
DISCLAIMER
提請注意
The information given on this sheet is to the best of our knowledge and accurate at the time of issuing.
Since conditions of use are beyond the manufacturer’s cool, information contained herein is without
warranty, implied or otherwise, and the suitability of the material for the use contemplated is the sole
responsibility of the buyer. The information contained on this data sheet is subject to modification at
any time due to our policy of modification and product development. Please check this date sheet is
current prior to using the product.
本說明書所提供信息均為目前我方所掌握最正確的資料,鑒于產品使用條件非我方所能控
制，此中信息不含，即僅在選取產品上對買方負責。由于我公司產品及生產工藝的不斷發
展，本說明書的內容也會隨時進行更改，此中所有信息均以我方確認為主。產品使用前，請確
認所持說明書為版本。
