> 商鋪首頁 > 產品展示 > 衡水市塑筋吸水排水軟管廠家_，PVC吸水和排水軟管，PVC砂 6'PVCS塑筋吸水和排水軟管 6'PVC 塑筋吸水和排水軟管

，PVC吸水和排水軟管，PVC砂 6'PVCS塑筋吸水和排水軟管 6'PVC 塑筋吸水和排水軟管

[152mm塑筋排水管

PVC砂礫軟管

螺旋增強PVC吸水軟管]

衡水市塑筋吸水排水軟管廠家

價格： 160.00

物流： 河北衡水市桃城區| 賣家支付運費

可銷售總量： 10000米

手機： 13343188982 郵箱： 1367864764@qq.com

傳真： 尚未完善 地址： 河北衡水市

在線詢盤聯系廠家：13343188982

在線詢盤

提交詢盤信息，一呼百應會為您匹配更多優質、合適的供應商！

*采購產品：

信息不能為空！請?zhí)顚懀?/p>

*采購量/單位：

采購量不能為空！

*期望價格：

元

價格不能為空！

*報價截止日期：

截止日期不能為空！

*聯系人：

聯系人不能為空！

*聯系電話：

聯系電話不能為空！

[152mm塑筋排水管 PVC砂礫軟管螺旋增強PVC吸水軟管]

我想要了解：

產品價格更多商品信息

請輸入您要咨詢的問題：

您的聯系方式：

郵箱：

手機：

詳細信息（，PVC吸水和排水軟管，PVC砂 6'PVCS塑筋吸水和排水軟管 6'PVC 塑筋吸水和排水軟管）

種類： pvc軟管
壁厚： 2mm-15mm
長度： 20m，30m，50m
工作壓力： 6-24mpa
品牌： 科恩
用途： 排水管
適用介質： 空氣，汽油，食品，粉末，化學品
應用： 用于輸送水，油和動力，磨料礦砂
溫度范圍： 10°C至+ 65°C（14°F至150°F）

Features:

1. No poison, no smell, no pollution, pull-resist

2. Corrosion- Rsist

3. Beautiful outlook

4. Soft, light and long usage life

Alias:

PVC suction hoses, spiral reinforced PVC suction hoses, water suction hoses with helix, PVC suction and discharge hoses, PVC grit hoses.

Application: Very ideally for conveying water, oil and power, abrasive mineral sands, grel, cement, chips, shings, construction, agricultural, and industrial service applications.

Temperature Range: -10 C to +65 C (14 F to 150 F)

Feature:

1. Good transparency and easy monitoring liquid flow.

2. Small bending radius and great ability of minus pressure resistance.

Structure:

1. Wall: High quality plasticized PVC

2. Reinforcement: Rigid PVC helix reinforced anti-choc spiral.

3. Characteristics: Strong, abrasion resistant, corrosion resistant and weather resistant. Its of stability and flexibility under performance.

Inside Diameter		Outside Diameter(mm)	Wall(mm)	working Pressure (MPa)	Burst Pressure (MPa)	Length Max.(m)	Weight(kg/m)	*Packing Measurement DH(mm)**
inch	mm	Outside Diameter(mm)	Wall(mm)	working Pressure (MPa)	Burst Pressure (MPa)	Length Max.(m)	Weight(kg/m)	*Packing Measurement DH(mm)**
1/4”	6	11	2.5	0.7	2.1	100	0.115	470*130
5/16”	8	14	3	0.7	2.1	100	0.156	500*130
3/8”	9	15	3	0.7	2.1	100	0.17	500*150
1/2”	12	18	3	0.6	1.8	100	0.22	550*170
5/8”	15	22	3.5	0.6	1.8	100	0.305	650*200
3/4”	19	26	3.5	0.6	1.8	50	0.38	650*150
1”	25	33	4	0.6	1.8	50	0.547	700*200
1-1/4”	32	41	4.5	0.5	1.5	40	0.85	800*170
1-1/2”	38	48	5	0.5	1.5	40	1.2	850*210
2”	50	62	6	0.5	1.5	40	1.6	980*250
2-1/2”	64	80	8.5	0.4	1.2	30	3	920*240
3”	75	92	8.5	0.4	1.2	30	3.9	1020*280
3-1/2”	89	107	9	0.4	1.2	30	4.5	1100*330
4”	102	120	9	0.3	0.8	30	5.2	1100*470
5”	127	141	7	0.2	0.6	20	5	1140*430
6”	152	166	7	0.2	0.6	20	6	1700*430

PVC screw suction hose

1. Made of: new PVC materials High quality

2. Specification: 3/4" to 20" 19mm-500mm

3. Length: 20m/roll,30m/roll, 50m/roll

4. Color:green,yellow,red,black,clear etc

5. diameter thickness as per the customers'requirement

6.Good flexibility. No poison and no smell.

7.Reinforced rigid plastic wire screw inserted into the inner wall of flexible PVC hose.

8.To be light in weight with good resistance to the hard weather conditions and minus pressure, and small bending radius.

9.Excellent resistance to pressure, external impacts, chemical, gases, light acids and saline water.

10.working Temperature: -5 centigrade degree to +65 centigrade degree.

11.Ideal subsititute for rubber hose, cement hose and metal hose in many areas.

12.Widely used for pumping and delivery fluids such as water ,oil and powder in agriculture, factory and construction , can fit to PVC pipe by PVC glue.

13.Especally ideal for ventilation and air conditioning system,industrial vacuum cleaner,and granulate conveying systems.

As suction and transport hose suitable for below substance.

Gaseous medias such as vapors and smoke.

Liquid medias.

Small granultes such as dusts,powders and ect.

agriculture, fishing and construction.

標簽： 152m PVC砂螺旋增強 152mm塑筋排水管 PVC砂礫軟管螺旋增強PVC吸水軟管衡水市塑筋吸水排水軟管衡水市塑筋吸水排水軟管廠家
