廣西梯式電纜橋架成型設備 梯式電纜橋架成型機

我司位于美麗的風箏之都--山東濰坊，成立于2005年，是集設備制造、模具加工、技術開發于一體的綜合性高科技校資企業我公司依托高校強大的設計研發團隊與科研支持，同時結合的設計制造理念，自主設計研發生產一系列鈑金自動加工成型設備。 company is located in Weifang, Shandong Province, a beautiful kite capital, founded in 2005. It is a comprehensive high-tech school-funded enterprise integrating equipment manufacturing, mold processing and technical development. Our company relies on the strong design and research team and scientific research support of colleges and universities, and combines the international advanced design and manufacturing concept. Independent design, research, development and production of a series of sheet metal automatic processing molding equipment. 槽式電纜橋架自動折彎成型設備工藝 Technology of automatic bending forming equipment for slot Cable Bridge 放料——導向——成型——焊接——打彎-----切斷——收料 Discharge-guide-forming-welding-bending-cutting-receiving 設備性能 Equipment performance 槽式電纜橋架自動折彎成型設備主要組成： The main components of automatic bending forming equipment for slot cable tray are as follows: 自動放料機、校平、送料部分、連續沖孔部分、定尺切斷部分、成型部分、收料臺、自動折框機、電器控制柜等部件組成。 Automatic discharge machine, leveling, feeding part, continuous punching part, fixed length cutting part, forming part, receiving table, automatic folding machine, electrical cool cabinet and other components. 槽式電纜橋架生產設備主要參數：Main parameters of production equipment for slot cable tray 電機功率：28kw Motor power: 28kw 電壓參數：380V/415V，50Hz, 3相電壓 Voltage parameters: 380V / 415V, 50Hz, 3 phase voltage 電氣控制：PLC自動控制 Electrical cool: PLC automatic cool 驅動電機：變頻電機驅動 Drive motor: frequency conversion motor drive 鋼帶厚度：0.5~1.5 mm Strip thickness: 0.5 to 1.5 mm 鋼帶寬度：≤1000mm Strip width: ≤ 1000mm 軋輥材質：鉻十二 淬火HRC58°-62° Roll material: chromium 12 quenched HRC58 °- 62 ° 液壓油型號：46# Hydraulic oil model number: 46# 材料規格： 1、Q235 2、不銹鋼 3、鍍鋅鋼板 Material specification: 1, Q2352, stainless steel 3, galvanized steel 折彎方式：自動折彎 Bend mode: automatic bend 生產速度：0-12 m/min Production speed: 0 to 12 m/min 切斷方式：液壓切斷 Cut-off mode: hydraulic cut-off 主要軋輥數量：14~23 Number of main rolls: 14-23 切斷尺寸公差：≤ ±0.3mm（長≤3000mm） Cut off dimensional tolerance: ≤ ±0.3mm (length ≤ 3000mm) 切斷模具材質：鉻十二鉬釩 Cutting die material: chromium twelve molybdate vanadium 氣源：0.6m3/Min；壓力為0.7MPa Gas source: 0.6m3 Minmin; pressure 0.7MPa 公司致力于高精度冷彎型鋼機各種非標型材結構研究、設計與開發。擁有ISO9001國際質量體系認證和歐盟CE認證，同時也是建設部金屬結構協會會員單位、也是高校的校辦企業，學院強大的科研隊伍保障了我公司產品的高質量標準。 The company is committed to high-precision cold-formed steel machine a variety of non-standard profile structure research, design and development. With ISO9001 international quality system certification and EU CE certification, but also the Ministry of Construction Metal structure Association member units, but also Shandong Science and school-run enterprises, the college's strong scientific research team to ensure the high quality standards of our products.
