清水混凝土模板體系
Concrete Formwork System
清水混凝土模板體系能夠 混凝土施工質量要求,充分表現清水混凝土設計效果。
面板采用華湄體系模板,次肋采用型材或木梁,主肋采用背楞,豎向邊框?yàn)榉戒摴埽姘?/span>
采用自攻螺釘從背面與次肋固定,主肋與次肋通過特制的鉤頭螺栓或者 U 型卡扣連接,模板內部通
過對拉螺栓固定連接,相鄰模板通過夾具連接。
1.:This formwork system greatly ensures the high quality of concrete surface effect.
2.:Panel could be Huamei plywood with high quality. The secondary rib is steel or H20 timber beam,
and the main rib is dual channel steel water. The vertical frame is square tube profile steel. The panel
connection adopts connection tie and the adjacent panels are connected by couplers.
華湄體系模板主要特點:板材強度高、彈性、韌性好,加工尺寸精度高,表面覆膜強度好、
耐磨性高、耐久性好、物理化學性能均勻穩定等,砼表面澆筑效果非常理想,正常使用周轉次數可
達15-25次,能保障飾面清水效果,提高施工效率、節省施工成本。
The advantages: high strength, flexibility, good toughness, size and high precision machining, surface
strength with plastic film, high wore resistance, durability, physical and chemical properties of uniform
stability and so on. The effect of concrete surface is very perfect in image, normal use of turnover up to
15-25 times. The plywood effectively improves the turnover rate of panel and reduces the cost.
