貼片型諧振器(SMD)8045

晶振 8.0*4.5*1.0 SMD Ctraylstal 6MHz-150MHz詳細內容

● 電氣參數 ELECTRICAL PARAMETERS          "項目 Project"    "符號 Symbpl"   "規格說明specifications"    "條件 Condition"     "標稱頻率Nominal Frequency  "f_nom 6.000000 MHz 150.00000MHz基頻 *1對于超出標準的規格說明，請聯系我們以便獲取相關信息。     "儲存溫度 Storage temperature range"  T_stg -40℃ to +85℃  裸存     "工作溫度 working temperature range"  T_use -20℃ to +70℃       "激勵功率 Excitation power"  DL 10 μW Max.  推薦: 1 μW ～ 100 μW     "頻率公差（標準） Frequency Tolerance"  f_tol ±20 × 10-6  +25 °C 對于超出標準的規格說明，請聯系我們以便獲取相關的信息。*1     "溫度特性 Temperature Characteristics"  PPM ±30  對于超出標準的規格說明，請聯系我們以便獲取相關的信息。*1     "并聯電容 Shunt Capacitance"  Pf 7.0pF max.       "負載電容 Load Capacitance"  CL 20/pF   可     "串聯電阻（ESR）Series resistance"  R1 如下表所示  -40℃ ～ +80℃, DL=100 μW     絕緣電阻  Insulation Resistance   500MΩ Min. @ DC100V        標稱驅動電平  Nominal Drive Level  μw  10  i nto 10 Ω     "頻率老化 Frequency aging"  f_age ±3×10-6/year Max.  +25℃, 年     ● 等效阻抗和振蕩模式 Equivalent Series Resistance and Mode of Operation          頻率范圍 Frequency Range   "等效阻抗 Equivalent impedance ESR(Ω)" "振蕩模式Oscillation mode"   8.000 MHz ≤ f_nom < <10.000 MHz   100 Ω Max.                 Fundamental   10.000 MHz ≤ f_nom < <12.000 MHz          80 Ω Max.                 Fundamental   12.000 MHz ≤ f_nom < 16.000 MHz    60 Ω Max.                 Fundamental   16.000 MHz ≤ f_nom < 20.000 MHz           50 Ω Max.                 Fundamental   20.000 MHz ≤ f_nom < 24.000 MHz    40 Ω Max.                 Fundamental   24.000 MHz ≤ f_nom < 50.000 MHz    30 Ω Max.                 Fundamental   50.000 MHz ≤ f_nom < 150.000 MHz   80 Ω Max.                 Third Overtone
