一、主要性能和特點:
1.整機結構緊湊,牢固,設計合理,簡潔。
2.采用光電眼控制系統,步進電機拉膜,可靠,性能穩定,噪音低。
3.采用變頻調速,運作更穩定,噪音更低,故障率低。
4.全自動從計量,充填制袋,日期打印到產品輸出一次性完成。
5.借用彈簧壓刀原理,氣動分切,五連包更加穩定。
Function and structure characteristics:
1. The machine is featured with compact structure, durable, logical design and Precise.
2. It adopts light sensor cool system, and is featured with reliable, stable performance.
3. Using VVVF, operation much more stable, low noise, with low malfunction.
4. It can finish automatically all processes, such as measuring, filling and bag mang.
5. With spring pressure knife principle, pneumatic cutting, 5 linking bags more stable
二、適用范圍:適合于膨化食品,蝦條,花生,瓜子,大米,種子,味精,玉米花等顆粒狀,條片狀,固物料的包裝。
Application: Suitable for packing puffed food, shrimp strip, peanut, cooked seeds, rice, seed, monosodium gluate, popcorn and other grain, strip and flake shaped solid material.
三、技術規格Technique specification:
| 機器型號 Machine model | RB-3220A顆粒立式自動包裝機 |
| 卷膜寬度Max. width of coiled film | 320mm |
| 制袋長度 Bag length | 30-200mm |
| 制袋寬度 Bag width | 50-150mm |
| 計量范圍 Measuring range | 50-500ml |
| 包裝速度 Packaging speed | 30-80bas/min |
| 卷材外徑 External diameter of coiled material | Max.300mm |
| 包裝膜厚度 Packing film thickness | 0.04-0.08mm |
| 使用電源規格Power supply specification | 220V50Hz.2kw |
| 機器重量Machine weight | 350kg |
| 包裝材料Packing Material | OPP/CPP.OPP/CE.MST/PE/PET/PE |
