Technical Specifications - Power Supply 890CS: 208–500Vac ±10%
- Inverter(DC-AC) 890CD: 320/560–705Vdc
- Converter (AC-AC) 890SD: 380–500Vac ±10% (Frames E thru K: 380–460Vac ±10%)
- Operating Temperature 0–45°C (Derate 2%/°C to 50°C max - Frame sizes G thru K: 0–40°C)
- Maximum Humidity 85% non-condensing
- Altitude 1000m ASL (Derate 1%/100m 1000–4000m max)
- Degree of Protection IP20: Frame sizes B,C,D, E, F IP00: Frame sizes G, H, J IP52: Frame size K
| Inputs/Outputs - Analog Inputs: 4 total, 2 configurable (0-10V, ±10V, 0-20mA, 4-20mA), +2 configurable (0-10V, ±10V)
- Analog Outputs: 2 configurable (0-10V, ±10V)
- Digital Inputs: 7 configurable (24V)
- Digital I/O: 2 configurable (24V)
- Relay Digital Output: 1 configurable (24V)* *3 additional 230V rated dry contacts (frames E-K)
| International Standards The AC890 complies to standard code when installed in accordance to manufacturers installation manual: - Includes Safe Torque Off (STO) feature (Frames B-F): - SIL3 or PLe level as per EN ISO13849 and EN61800-5-2
- Conforms to EC Directive 89/336/EEC in compliance with standard: - EN61800-3 (Environment 2)
- Conforms to EC Directive 73/23/EEC in compliance with standard: - EN50178 (Low Voltage)
- Complies with UL508C safety standard
- Complies with CE, UL e c-UL
|  AC890 System Drives are modular AC drive units that can be combined to form a complete multi-section drive system, sing space, reducing wiring, and providing unmatched system performance. Safe Torque Off feature (SIL3 or PLe level as per EN ISO13849 and EN61800-5-2) is provided in frames B-F. The AC890 can cool everything from induction motors to servo motors. AC890 provides V/F, sensorless vector, closed-loop flux vector and servo ition cool; from simple AC motor cool sections to more demanding sections. The AC890 comes in a wide variety of sizes and ratings and input and output types, making it the right solution for virtually any motion cool project. 5-Mode Frequency Converter: - V/F, Sensorless Vector, Flux Vector, Servo Drive, Line Regenerative (AFE)
- Built-in EMC Filters
- 2 Performance Levels (Advanced and High Performance)
- COMMS Options ailable
COMMON BUS Drives (CD) are individual motor output sections that easily connect to a COMMON BUS Supply (CS)with a unique, easy-to-install DC bus bar system (SSD Rail). COMMON BUS Made Easy! DC bus terminals are located at top of each drive section. Easy to use screw clamps secure the high power bus bars. This low cost, compact design significantly reduces wiring in common bus systems, sing time and material cost. COMMON BUS Drives (CD) - have internal DC fuses
- Need no reactors
- Provide access to all feedback and networking options
STANDALONE Drives (SD) The AC890 Standalone Drives are complete AC-input-to-AC motor output cooller with power input and output terminals, and access to all feedback and networking options. AC890CD/AC890SD Cool Board - Programming Port (USB)
- Torque and Speed Analog Outputs
- Health Contact
- 24VDC Cool Supply - Programming without Power Supply
- Digital I/O
- Motor Thermistor Input
- Running and Zero Speed Signal Output
Performance Levels AC890 frequency converters offer the level of performance that best suits your application needs. With 2 different performance levels, AC890 system allows the maximum flexibility of use. - Advanced Performance Basic LINK VM function blocks: math functions, Boolean logic, timers, counters, One shots, threshold comparators, latches, plus: motion cool firmware with added ition loop, motion cool function blocks, move incremental, move absolute, move home, line drive master ramp and section cool, winder blocks (SPW, CPW), full function PID, state machine, and others.
- High Performance All Advanced Performance features, plus: Library of pre-engineered application specific LINK VM function blocks such as: shaftless printing, cut-to-length, precision winding, trersing, and others.
Shaftless Registration Cool Solutions for Printing Mechanical line shafts for printing are easily replaced with individual AC890 drives, capable of precise synchronization and printing registration adjustment to each section, guaranteeing perfect alignment of each color. AC890 High Performance Level features a library of pre-engineered application specific LINK VM function blocks, including shaftless printing, cut-to-length, precision winding, trersing, and others. FireWire protocol (IEEE1394) ensures data synchronization for the printing register cool. - 125?S Cycle time
- Time Synchronization
- Deterministic Network
Active Front End: Line Regenerative Systems Common Bus Drive sections can also be configured as Active-Front-End Input Sections, providing true lineregenerative 4-quadrant cool with no harmonics and 1.0 power factor. The AC890 with AFE can also be configured for grid-tie inverter applications. Requirements - Pre-charging Circuit
- LCL Filter
Performance - Fully Bidirectional Power Flow
- Overload 150% for 60 secs
- Sinusoidal Input Current
- Complies with IEEE 519
Larger AC890 systems can be matched with separate higher power Active Front End units. Multiple rows of AC890 Common Bus Drives are bridged together using Common Bus Adapter modules.AC890 Series CS/CD AC890 Series CS/CD units provide a common bus solution for multi-section drive applications. Multiple AC890 Series CD Common Bus Drive inverter sections can be combined with a single AC890 Series CS Common Bus supply unit, achieving substantial space sings and peripheral component sings within the enclosure. Additional 890 Series CS supply units may be paralleled to provide greater DC bus supply amperage. How to Pick a CS - Select the AC890CD (common-bus drives), one for each section.
- Select the AC890CS (common-bus supply) module by adding the HP (or currents) of all the CD drives.
- Select a reactor and braking resistor kit
- Order the common bus bar and exhaust duct kit from the options section
AC890CS Power Supply Unit - up to 162A
- Power Supply 208–500VAC
- Built-in Dynamic Braking Unit
- DC BUS Supply Output
- Diagnostic Operator Panel
AC890CS Cool Board - 24Vdc Supply Cool
- HMI Interface Connection
- Three-phase Supply Selector
- Configurable Analog Output
- Prewarning Output
- Alarm Output
| AC890 Common Bus Supplies used with 230 - 500Vac (+/-10%) 3 phases | | Part Number | Frame | HP@ 460Vac | HP@ 230Vac | Input Amps | | 890CS/5/0032B/B/00/N/EN | B | 25 | 10 | 32 | | 890CS/5/0054B/B/00/N/EN | 45 | 20 | 54 | | 890CS/5/0108D/B/00/N/EN | D | 75 | 40 | 108 | | 890CS/5/0162D/B/00/N/EN | 135 | 60 | 162 | AC890CD Inverters from 1.5 to 180A - 320, 650, 705VDC Power Supply
- Standard Equipped Keypad
- Common Options with AC890SD
- COMMS Options ailable
| AC890 Common Bus Drives 208 - 230Vac (+/-10%) | | Part Number | Frame | HP@ 230Vac | Output Amps@ 230Vac | | 890CD/2/0003B/N/00/A/US | B | 0.75 | 3 | | 890CD/2/0005B/N/00/A/US | 1.5 | 5.5 | | 890CD/2/0007B/N/00/A/US | 2 | 7 | | 890CD/2/0011B/N/00/A/US | 3 | 11 | | 890CD/2/0016B/N/00/A/US | 5 | 16.5 | | 890CD/2/0024C/N/00/A/US | C | 7.5 | 24 | | 890CD/2/0030C/N/00/A/US | 10 | 30 | | AC890 Common Bus Drives 380 - 500Vac (+/-10%) | | Part Number | Frame | HP@ 460Vac | Output Amps@ 460Vac | | 890CD/5/0002B/N/00/A/US | B | 1 | 2 | | 890CD/5/0003B/N/00/A/US | 1.5 | 3.5 | | 890CD/5/0004B/N/00/A/US | 2 | 4.5 | | 890CD/5/0006B/N/00/A/US | 3 | 5 | | 890CD/5/0010B/N/00/A/US | 5 | 8 | | 890CD/5/0012B/N/00/A/US | 7.5 | 12 | | 890CD/5/0016B/N/00/A/US | 10 | 14 | | 890CD/5/0024C/N/00/A/US | C | 15 | 24 | | 890CD/5/0030C/N/00/A/US | 20 | 27 | | 890CD/5/0039D/N/00/A/US | D | 25 | 35 | | 890CD/5/0045D/N/00/A/US | 30 | 40 | | 890CD/5/0059D/N/00/A/US | 40 | 52 | | 890CD/4/0073E/N/00/A/US | E | 50 | 73 | | 890CD/4/0087E/N/00/A/US | 60 | 87 | | 890CD/4/0105F/N/1F/A/US | F | 75 | 100 | | 890CD/4/0145F/N/1F/A/US | 100 | 130 | | 890CD/4/0156F/N/1F/A/US | 125 | 156 | | 890CD/4/0180F/N/1F/A/US | 150 | 180 | AC890SD Series from 1.5 to 1681A AC890SD Series (Stand Alone) frequency converters are independent units that can be powered either with mains three phase voltage or via DC bus. 890SD Series comes in a wide choice of sizes, suitable for every type of application, from small industrial machines to high-powered large plants (e.g. rolling mills, paper mills). They are also ideal for applications where single units are machine mounted (e.g. printing units). - Direct Mains Supply or Via DCBUS
- Built-in Dynamic Braking Unit
- Standard with Keypad
- Common Options with 890CD
- COMMS Options ailable
| AC890 Stand-alone Drives 208-240Vac (+/-10%) Input 3-phase | | Part Number | Frame | HP@ 230Vac | Output Amps@ 230Vac | | 890SD/2/0003B/B/00/A/US | B | 0.75 | 3 | | 890SD/2/0005B/B/00/A/US | 1.5 | 5.5 | | 890SD/2/0007B/B/00/A/US | 2 | 7 | | 890SD/2/0011B/B/00/A/US | 3 | 11 | | 890SD/2/0016B/B/00/A/US | 5 | 16.5 | | 890SD/2/0024C/B/00/A/US | C | 7.5 | 24 | | 890SD/2/0030C/B/00/A/US | 10 | 30 | Note: The AC890 comes in two performance level configurations, Advanced and High. The part #’s shown above 890SD/x/xxxxx/x/xx/A/xx are for Advanced models. For High Performance models, replace the Performance Level field designator with an H. | AC890 Stand-alone Drives 380 -500Vac (+/-10%) Input -3 Phase: Frames B thru D 380 -460Vac (+/-10%) Input -3 Phase: Frames E and Higher | | Part Number | Frame | HP@ 460Vac | Output Amps@ 460Vac | | 890SD/5/0002B/B/00/A/US | B | 1 | 2 | | 890SD/5/0003B/B/00/A/US | 1.5 | 3.5 | | 890SD/5/0004B/B/00/A/US | 2 | 4.5 | | 890SD/5/0006B/B/00/A/US | 3 | 5 | | 890SD/5/0010B/B/00/A/US | 5 | 8 | | 890SD/5/0012B/B/00/A/US | 7.5 | 12 | | 890SD/5/0016B/B/00/A/US | 10 | 14 | | 890SD/5/0024C/B/00/A/US | C | 15 | 24 | | 890SD/5/0030C/B/00/A/US | 20 | 27 | | 890SD/5/0039D/B/00/A/US | D | 25 | 35 | | 890SD/5/0045D/B/00/A/US | 30 | 40 | | 890SD/5/0059D/B/00/A/US | 40 | 52 | | 890SD/4/0073E/B/00/A/US | E | 50 | 73 | | 890SD/4/0087E/B/00/A/US | 60 | 87 | | 890SD/4/0105F/B/1F/A/US | F | 75 | 100 | | 890SD/4/0145F/B/1F/A/US | 100 | 130 | | 890SD/4/0156F/B/1F/A/US | 125 | 156 | | 890SD/4/0180F/B/1F/A/US | 150 | 180 | | 890SD/4/0216G/ * /1F/A/US | G | 175 | 216 | | 890SD/4/0250G/ * /1F/A/US | 200 | 250 | | 890SD/4/0316G/ * /1F/A/US | 250 | 316 | | 890SD/4/0361G/ * /1F/A/US | 300 | 361 | | 890SD/4/0420H/ * /1F/A/US | H | 350 | 420 | | 890SD/4/0480H/ * /1F/A/US | 400 | 480 | | 890SD/4/0520H/ * /1F/A/US | 450 | 520 | | 890SD/5/0590J/ * /1F/A/US | J | 500 | 590 | | 890SD/5/0685K/ * /1F/A/US | K(2xG) | 600 | 685 | | 890SD/5/0798K/ * /1F/A/US | K(2xH) | 700 | 798 | | 890SD/5/0988K/ * /1F/A/US | K(2xH) | 800 | 988 | | 890SD/5/1028K/ * /1F/A/US | K(3xG) | 900 | 1028 | | 890SD/5/1120K/ * /1F/A/US | K(2xJ) | 1000 | 1120 | | 890SD/5/1197K/ * /1F/A/US | K(3xH) | 1000 | 1197 | | 890SD/5/1482K/ * /1F/A/US | K(3xH) | 1300 | 1482 | | 890SD/5/1681K/ * /1F/A/US | K(3xJ) | 1500 | 1681 | * The Braking switch is optional on these models–B is braking, N is no brake.. Note: The AC890 comes in two performance level configurations, Advanced and High. The part #’s shown above 890SD/x/xxxxx/x/xx/A/xx are for Advanced models. For High Performance models, replace the Performance Level field designator with an H. | Dimensions | | Frame | H | W | D | | AC890 Frame B | 17.1 (433) | 2.9 (72) | 10.2 (258) | | AC890 Frame C | 4.6 (116) | | AC890 Frame D | 6.3 (160) | | AC890 Frame E | 26.3 (668) | 10.1 (257) | 12.3 (312) | | AC890 Frame F | 28.3 (720) | 13.4 (355) | | AC890 Frame G | 41.0 (1042) | 17.9 (456) | 18.3 (465) | | AC890 Frame H | 46.3 (1177) | 22.5 (572) | | AC890 Frame J | 50.7 (1.288) | 26.6 (675) | | AC890 Frame K | For K Frame Dimensions- Consult Factory | Cables and Connectors | Cables | | Part Number | Deion | | CM471050 | 890 USB Programming Cable | | 8905/FWCBL200/00 | 200 mm FireWire Cable (B Frame to a B, C, and D Frame) | | 8905/FWCBL280/00 | 280 mm FireWire Cable (C, D Frame to a B, C, and D Frame) | | 8905/FWCBL1000/00 | 1000 mm FireWire Cable (Rack to Rack) | | 8905/FWCBL4500/00 | 4500 mm FireWire Cable (Rack to Enclosure) | | Bus Bar System | | Part Number | Deion | | BH465850 | 1 m DC SSD Rail/Bus Bar 140A (UL) | | BC465938U200 | 200 mm Insulator for DC Bus Bars | | BA469216 | Grounding Bus Bar 1m (CS/CD only) | | Assembly Kit | | Part Number | Deion | | BA465900 | Clips for Fitting on DIN rail | | BA465887 | Cool Cable Support | | BA465888 | Supply Cable Support | | LA471585 | I/O Terminal Interface Module | | CM471585U001, U002, U003 | Drive to module cable for LA471585 (1 meter, 2 meter, 3 meter) | | CM471592 | Extended module to module cable for LA471585 (2 meter) | | 8905/DUCTKIT/190 | Duct Kit (1 m Exhaust Duct for Frames B, C, and D + 1 Fan Kit Rated at 190 CFM) | Options | Feedback and I/O | | Part Number | Deion | | 8902/E1/00/FF | Abs Sin/Cos (Endat 2.1) | | 8902/EQ/00/FF | Encoder (Incremental Quadrature) | | 8902/M1/00/FF | Abs Sin/Cos (Endat 2.1) w.Registration | | 8902/RE/00/FF | Resolver | | 8903/EP/00/FF | Reference Encoder Input | | 8903/AI/00/FF | High Resolution Analog and Reference Encoder Input | | Comms Options | | Part Number | Deion | | 8903/FA/00/FF | FireWire 1394a Communication Module | | 8903/DN/00/FF | DeviceNet Communication Module | | 8903/PB/00/FF | ProfiBus Communication Module | | 8903/CN/00/FF | CoolNet Communication Module | | 8903/CB/00/FF | CanOpen Communication Module | | 8903/IP/00/FF | Ethernet/IP Communication Module | | 8903/IM/00/FF | Ethernet Modbus/TCPCommunication Module | | 8903/CT/00/FF | EtherCAT Communication Module | | 8903/PN/00/FF | Ethernet PROFINET Module | | Keypads | | Part Number | Deion | | 6901/00/G | Alphanumeric Multilingual Keypad | | 6502/00/G | Remote Mounting Kit for 6901 Keypad Including 3m Cable | | 6911 | Enhanced alphanumeric keypad with Rotary Selector | | Firewire Repeaters | | Part Number | Deion | | LA471480 | Firewire Repeater 100Mb/100ft | |
