S型稱重傳感器PLR9363-AS-50kg75kg100kg200kg250kg500kg750kg1t

品牌: 拉姆齊Ramsey 美國Ramsey稱重傳感器9363傳感器 產品名稱：美國Ramsey稱重傳感器 產品品牌：美國拉姆齊拉壓式稱重傳感器 產品類型：S型稱重傳感器 產品型號：9363-50kg-2000kg稱重傳感器 美國Ramsey稱重傳感器9363產品特點： -S型稱重傳感器； -合金鋼設計,不銹鋼可選； -雙向（張力/壓縮）； -合理化輸出； -可選功能:調頻批準可以使用； -防潮膠密封； -綜合精度：0.02%; -防護等級：IP65； RAMSEY CERTIFCATE OF CONFORMANCE CALIBRATION DATA MODEL:9363 Cap:50kg RecommendedExcitaion 10VACorDC CompensatedTemp.Range -10to40℃ MaximumExcitation 15VACorDC OperatingTemp.Range -20to60℃ OutputatratedLoad 1.5001mv/v ZeroBalance ±3.0％FS Non Linearity ＜0.025％ Input Resistance 410±10∩ Hysteresis ＜0.025％ Output Resistance 350±3∩ Creep(30minutes) 0.0300％ InsuIation Resistance(50VDC) ＞5000M∩ Non-Repeatability ＜0.020％FS Deflection at Rated Load Nil Zero Return(30minutes) 0.0300％ Safe Overload 150％ Temp.Effect/℃ on span ＜0.0015％ Ultinmate Overload 200％ Temp.Effect/℃ on zero ＜0.0026％ WIRING CODE +Excitation:Green -Excition:BIACK +Sense:Blue -Sense:Brown +Output:Red -Output:White CHINA JJG 669-2003 Data obtained utilizing standards to the National Instional Institute of Standards＆ Technology SAFETY INSTRUCTIONS To ensure sufficient overload capacity for the designed load,the dimesions of dll mounying and strcural elements haS to bo calculated. Ln particular,upright weighing objecte(vessels and the like)haS to be safeguarded against the weighing installation turning over or being shifted. In the event of a break in suspension.Load cell,or mounting part etc,erpresnting a hazard to health abfd/or sa fety and / or damage to goods . additional safety devices are necessity.
